10. CONNECTORS AND CABLE SPECIFICATIONS
10.2 Receptacle contacts
TTControl recommends the following receptacle contacts for mating connectors:
Connector Description Note Part no. Supplier
C1 For stranded wire with 0.50 mm
2
cross sectional area [AWG20]
1 3-1447221-4 TE Connectivity
C1 For stranded wire with 0.75 mm
2
to 1.25 mm
2
cross sectional area
[AWG18 –16]
1 3-1447221-3 TE Connectivity
Note 1 Superseal 1.0 mm socket crimp contact.
10.3 Cavity plugs and blind plugs
TTControl recommends:
Connector Description Part no. Supplier
C1 Cavity plugs for unconnected pins 4-1437284-3 TE Connectivity
A, B, C, D Blind plug for the connector D4Z023-002Z Rosenberger
NOTE
Connectors and/or cavity and blind plugs must be installed to ensure that the device is water tight.
10.4 Tools
Connector Description Note Part no. Supplier
C1 CERTI-CRIMP straight action
hand tool with fixed dies
1 1454509-1 TE Connectivity
A, B, C, D Repair Tool Kit RosenbergerHSD 2 D4W006-SET Rosenberger
Note 1 TTControl recommends the instruction sheet 411-78017 from TE Connectivity.
Note 2 TTControl recommends ordering the cable harnesses for connectors A, B, C, and D
from a professional cable harness manufacturer.
