8. POWER MODES
Power-off → Power-on 1 Wake-up event:
• rising edge on Terminal 15 signal
• rising edge on Wake-up signal
• reception of wake-up pattern on a wake-up enabled
CAN interface
• reception of wake-up pattern on a wake-up enabled
100BASE-T1 interface
• real-time clock with configured alarm-time and date
Power-on → Suspend At application request
Power-on → Disconnect 2 Terminal 30 disconnected from power supply
Suspend → Power-on Wake-up event:
• rising edge on Terminal 15 signal
• rising edge on Wake-up signal
• reception of wake-up pattern on a wake-up enabled
CAN interface
• reception of wake-up pattern on a wake-up enabled
100BASE-T1 interface
• real-time clock with configured alarm-time and date
• touch event
Suspend → Disconnect 2 Terminal 30 disconnected from power supply
Note 1 Ensure that the device remains disconnected for a minimum of one second when
switching the device off and on again (corresponds to power mode transistion: Power-
off → Disconnect → Power-on).
Note 2 Performing this mode transistion is not recommended as all unsaved data will be lost,
and all operations running will be terminated in an uncontrolled manner. Users are
advised to power-off by setting Terminal 15 to low, and waiting until the application
performs a controlled shut down of the device.
