Jumper Cable BELDEN 8723
Crimp a male contact on each of the four wires. The wire of shielding is to be crimped in the same
contact as the black wire.
Jumper Cable BELDEN 8723
4 Male Contacts
- Put a 45 mm Heat Shrinkable Tube on the Jumper Cable.
Male Contacts
45 mm Heat Shrinkable Tube
