Let cool the Tube in driving position, connector downward.
Proceed in the same way for the other end with a Female Connector and
Female Contacts.
DO NOT CONNECT THE WIRE OF SHIELDING:
Female Contacts
45 mm Heat Shrinkable Tube
1
2
3
4
Green
White
Black
Red
Female Connector
C
L
I
P
P
E
R
Female Connector
Press and Draw
The Red Plate and the
rentrée
Contacts are blocked
C
L
I
P
P
E
R
C
L
I
P
P
E
R
1
4
3
2
