IV TEST PROCEDURE
All the material was installed; you have just turned the FG-SYS digital unit on, it is now necessary to
test the system.
1. FUNCTION TEST
The digital unit automatically carries out a general test during the powering of the system. This
function TEST is also available from the MONITORING mode by pressing the key [T].
An audible alarm sounds and the luminous witness becomes red, it turns green and the display
indicates that the circuits are under test.
The digital unit tests one circuit after the other. Three circuits of cables are available on the digital unit.
In the majority of the cases only one circuit is used. The display indicates the length of each cable, as
well as the overall length of all of the circuits.
Once the test is finished, the digital unit passes into MONITORING mode:
Caution: Each change on the circuit of cables (change of cable, new provision) forces you to activate
the TEST procedure.
CIRCUITS UNDER TEST
CIRCUITS UNDER TEST
CABLE # 1: 7m
001-COMPUTER ROOM 1
TOTAL CIRCUIT: 7m
ON 14/05/2014 15:05
« SITE NAME »
UNDER SURVEILLANCE
[ H ] isto [ T ] est [ M ] enu
CIRCUITS UNDER TEST
CABLE # 2: 15m
002-COMPUTER ROOM 1
TOTAL CIRCUIT: 22m
CIRCUITS UNDER TEST
CABLE # 3: 7m
003-TGBT
TOTAL CIRCUIT: 29m
