TUNGSTEN T series ATV winch
10
bolt on the bottom of the motor and remove water as soon as possible. You should
use the winch within 3 days, to help remove water from winch motor parts
Lubricate the cable periodically, to replace a new cable as soon as possible if it glitch
occurs, fracture, and creases.
You should clean and lubricate after using; Also should store the winch in the dry and
drain place, disengage the clutch, and avoid children to contact and play.
Each assembly or connection screw is loosen, or corrosion , please repair and replace
timely
Troubleshooting
NO.
SYMPTOM POSSIBLE SUGGESTED
1
Motor does
not turn on
- Switch Assembly
not connected
property
- Loose battery
cable Connections
- Solenoid
malfunctioning
- Defective Switch
Assembly
- Defective motor
-Water has entered
motor
- Insert Switch Assembly all the way
into the connector.
- Tighten nuts on all cable connections.
- Tap solenoid to loosen contacts.
Apply 12volts to coil terminals directly A
clicking indicates proper activation.
- Replace Switch Assembly
- Check for voltage at armature port
with Switch pressed. If voltage is
present replace motor.
- Allow to drain and dry. Run in short
bursts without load until completely dry.
2 Motor rotates
but Cable
drum does
not turn
- clutch not
engaged
-Move clutch to the” in” position. If
problem persists, a qualified technician
needs to check and repair.
3 Motor runs
slowly or
without
normal
power
Insufficient current
or voltage
- Battery weak, recharge. Run winch
with vehicle motor running.
- Loose or corroded battery cable
connections. Clean ,tighten, or replace
4 Motor runs
too hot
- Long period of
operation
-Let winch cool down periodically
5 Winch runs in
one direction
only
- Defective or stuck
solenoid
- Defective Switch
Assembly
- Tap solenoid to loosen contacts.
- Repair or replace solenoid.
- Replace Switch Assembly
