TUNGSTEN T3000 - Winch Packing List

TUNGSTEN T series ATV winch
13
UTV T4000 T4000S T4500 T4500S
Rated line pull
（ ）
4000lbs 1814kgs single line
（ ）
4500lbs 2041kgs single line
Permanent
magnetic Motor
(1.6hp)/1.2kw output, DC 12V (1.8hp)/1.3kw output, DC 12V
Rope length
6mmx 10m
(6/25”x32.8’)
6mmx 10m
(6/25”x32.8’)
6.3mmx 10m
(1/4”x32.8’)
6.3mmx 10m
(1/4”x32.8’)
Gear Train 3 stage planetary
Gear Ratio 198 :1
Drum size
50mmx76.5mm (1.97” x 3”)
Bolt pattern
124mmX76mm (4.88” x 3”)
Dimensions
334*114*120mm (13.15” x 4.49” x 4.72”)
N.W
10kgs (22lbs) 8.5kgs (18.7 lbs) 11kgs (24lbs) 9.5kgs (21 lbs)
6. Winch Packing List
No
DESCRIPTION QTY
No
DESCRIPTION QTY
1
Winch Assembly with Wire Rope
1 7
Cable stopper
1
2
Power Cord/Switch Assembly
1 8
Contactor
1
3
Handlebar control
1 9
Bolts bag
1
4
Contactor protector
1 10
Strap
1
5
Fairlead/hawse fairlead
1 11
Clevis Hook
1
6
Mounting plate
1 12
Manual
1
