TUNGSTEN T3000 - Specification

TUNGSTEN T series ATV winch
12
NO . QTY Description NO . QTY Description
1 1 Clutch knob 15 2 O-ring for water proof
2 1 O-ring 16 1 Drive Shaft
3 1 Gear box body 17 1 Drum
4 1 Gear ring 18 1 Spring
5 1 Slide block for clutch 19 1 Brake gear
6 1 Sun gear 20 1 Spring
7 1 bushing 21 1 Brake base
8 1 Gear carrier assembly stage 1 22 1 Bushing for water proof
9 2 bushing 23 2 Tie rod
10 1 Gear carrier assembly stage 2 24 4 Screw
11 1 Gear carrier assembly stage 3 25 1 Drum support motor side
12 1 gasket 26 1 Bearing bushing
13 1 Gear box cover 27 1 Gasket
14
2
D
rum bushing
28
1
B
earing
29 1 Motor
5. Specification
ATV T2500 T2500S T3000 T3000S T3500 T3500S
Rated line pull
（ ）
2500lbs 1134kgs single
line
（ ）
3000lbs 1360kgs single
line
（ ）
3500lbs 1588kgs single line
Permanent
magnetic
Motor
(1.3hp)/0.97kw output, DC
12V
(1.4hp)/1.0kw output, DC 12V (1.5hp)/1.1kw output, DC 12V
wire/synthetic
rope
4.5mmx15m
(3/16”x49.2’)
5mmx 10m
(1/4”x32.8’)
4.5mmx15m
(3/16”x49.2’)
5mmx 10m
(1/5”x32.8’)
4.5mmx15m
(3/16”x49.2’)
5mmx 10m
(1/5”x32.8’)
Gear Train
3 stage planetary
Gear Ratio
198 :1
Drum size
50mmx76.5mm (1.97” x 3”)
Bolt pattern
124mmX76mm (4.88” x 3”)
Dimensions
334*114*120mm (13.15” x 4.49” x 4.72”)
N.W
9kgs (20lbs)
7.4kgs (16.5
lbs)
9kgs (20lbs)
7.4kgs (16.5
lbs)
9kgs (20lbs) 7.4kgs (16.5 lbs)
