TurboChef ENCORE 2

A-12 ENCORE APPENDIX  REPLACING OVEN COMPONENTS
NEMA 6-30P
IEC 309, 3-pin
IEC 309, 5-pin
Clipsal, 5-pin
Power Components
DANGER: Before removing any oven part, be sure the oven has completed “cooling down” (see
“Step 9” on page 11) and is removed from the power source.
NOTE: For clarity, some components have been removed from the illustrations below.
NEMA L6-50, PSE,
4-blade
IEC 309, 4-pin
NEMA L6-50, PSE,
3-blade
1
3
3
4
17
6
7
10 11 12
13
14
15
16
