A-3
ENCORE APPENDIX REPLACING OVEN COMPONENTS
Figure
Reference #
Item Description Item Part Number Fastener Description Fastener Part Number(s)
1 Badge, Logo, Encore/Encore 2 ENC-1192 Nut, Push, 1/8” 101293 (qty 2)
2 Catalytic Converter, Vent Tube RWD-9191 None None
3 Cover, Exhaust Tube ENC-1080 Screw, #8 x 3/8, Ph Mod Truss Hd, Cres 101682 (qty 6)
4 Cover, Left Side, Black ENC-1109-9005
Screw, #8 x 3/8, Serr Ph Truss Hd, Bk Zinc
Screw, #8 x 1/2, Security, Torx Hd, Bk Oxide
101369 (qty 7)
102756 (qty 1)
5 Cover, Right Side, Black ENC-1108-9005
Screw, #8 x 3/8, Serr Ph Truss Hd, Bk Zinc
Screw, #8 x 1/2, Security, Torx Hd, Bk Oxide
101369 (qty 7)
102756 (qty 1)
6 Cover, Top, Black ENC-1133-9005
Screw, #8 x 3/8, Ph Mod Truss Hd, Cres
Screw, #8 x 1/2, Serr Ph Truss Hd, Sheet Mtl
101682 (qty 5)
101688 (qty 4)
7 Filter, Air ENC-1114 None None
8 Filter Bracket ENC-1113 Screw, #8 x 3/8, Ph Mod Truss Hd, Cres 101682 (qty 4)
9 Housing, Exhaust Tube ENC-1079 Screw, #8 x 3/8, Ph Mod Truss Hd, Cres 101682 (qty 6)
10 Leg, Plastic, Black (x4) HHB-3205 None None
11 Lower Front Panel ENC-1103-T001 None None
12 Pad, Abrasive, Non-Slip (x4) NGC-1187 None None
13 Panel, Rear ENC-1105 Screw, #8 x 3/8, Ph Mod Truss Hd, Cres 101682 (qty 7)
14 Rack, Oven ENC-1216 None None
