Captive bolt stunner device
Test shots into the air are to be avoided.
Always re test shots only into adequately strong and rmly
mounted wooden supports(square timber min. 10 x 10 cm).
In the event of ammunition failing, the triggering mechanism
must be actuated again. If there is still no ignition, please wait
around 30 seconds; then unscrew the headpiece completely
and remove the ammunition carefully by means of the trigger.
The striking pin must not be cocked at this time.
Testing the striking pin
6.4 Removing the red blank cartridges
With the headpiece unscrewed, ensure that the tip of the stri-
king pin does not project out of the headpiece as otherwise
this could result in premature ring when it is screwed back
on again. If the striking pin is defective, it can only be repla-
ced as a complete unit. To do so, order a complete striking pin
set.
Maintenance work must be carried out exclusively by the ma-
nufacturer or their authorized representatives unless the user
is installing only parts designated as replacement parts (see
chapter 13.2 – Accessories and spare parts lists) by the manu-
facturer within the scope of their maintenance work.
Aer unscrewing the headpiece, the blank cartridge can usually be easily
removed with the ngers. If the blank cartridge is jammed, it can be remo-
ved with the extractor located at the end of the trigger by hooking it into
the groove on the intermediate piece (cartridge receiver).
The cartridge receiver should then be immediately cleaned of any powder
residue and other contaminants with the small brush.
