22 Captive bolt stunner device
Within the scope of the Ordinance on Industrial Safety and Health (Be-
triebssicherheitsverordnung), the operator of a captive bolt stunner must,
in accordance with §30 of DGUV Vorschri 56, submit the unit for inspecti-
on to the manufacturer or his authorised representative within 2 years,
rounded up to the end of the month, or immediately in the event of signi-
cant functional defects.
The period for the rst repeated test starts with the shipping of the device
to the operator.
The start of this period should be veried through a purchase certicate,
which the manufacturer or dealer will have enclosed when handing over
each captive bolt stunner. The corresponding form can be lled in by the
operator or dealer on the last page of these operating instructions as proof.
11. Test specications and repeat testing
Acoustic measurement for fastener driving devices GK2 dt. Fassung EN 12549:1999+A1:2008;
Red cartridge (460mg propellant powder)
Noise pressure level at measurement surface 98 dB(A)
Emitted noise pressure at workplace (max. 17 shots/h) 82 dB(A)
Sound power level 111 dB(A)
Peak noise pressure level 139 dB(A)
Key parameters acc. to 1099/2009/EC
Speed ±2 m/s and resulting energy for cartridges
Kartusche Blitz Kerner Bullen Blitz Kleiner Blitz Blitz Schlag
Green
42m/s - 185J 42m/s - 185J 20m/s - 50J
Yellow
46m/s - 222J
Blue
47m/s - 232J
Red
49m/s - 252J 53m/s - 323J
Vibration measurement with red cartridge (460mg) nach DIN EN ISO 5349-1, 20643
und DIN ISO/TS 15694 und 8662-11
Total vibration at 17 shots/h 2,5m/s²
