e-Boost-40 Instructionse-Boost-40 Instructions
Page 3
PART NUMBER
FG-EBOOST-40FG-EBOOST-40
1. BEFORE YOU START - IMPORTANT TIPS
- This Model e-Boost is capable of controlling boost pressures up to 2.72bar (40psi or 272kpa), for boost applications up to 4.08bar (60psi
or 408kpa) use FG-EBOOST-60.
- Turbosmart recommends that your e-Boost is fitted by an appropriately qualified technician.
- Consult your local tuning specialist before setting your boost pressure
- Setting boost beyond your engines capability can result in severe engine damage or failure!
- Turbosmart recommends that the engines Air/Fuel ratio is checked once the desired boost pressure is set, any increase in boost pressure
can cause the engine to run LEAN
- To safeguard against pinging or detonation, always use the highest octane fuel available
- A Turbosmart Fuel Cut Defender may need to be used in conjunction with your e-Boost, Please check out the www.turbosmart.com.au or
your nearest Authorised Turbosmart Dealer for more information on Fuel Cut Defenders
- Turbosmart recommends that boost pressure is set using a Dynamometer and not on public roads
2. INSTALLATION
2a. Packing list
The following components have been supplied with your e-Boost.
Quantity Description Use
1 e-Boost
1 e-Boost solenoid Use in conjunction with e-Boost
2 M3 Screws Secure e-Boost solenoid
2 M3 Nylock nuts Secure e-Boost solenoid
1 Wiring loom Connect e-Boost to vehicle
1 Earth eyelet Connect to chassis
100 mm Heat shrink Shield solder joints
2000 mm Figure eight wire Connect wiring loom to e-Boost solenoid
1 5 Amp fuse Connect to 12 Volts – see wiring
10 Cable ties Secure wiring
1 Panel mounting bracket Secure e-Boost to panel
2 M4 nuts Secure panel mount bracket
2 M4 spring washers Use with M4 nuts
1000 mm 2.5mm ID Polyurethane hose Connect to back of e-Boost
1000 mm 3mm ID Silicon hose Join polyurethane hose to intake manifold
1 Connecting barb Connect silicon hose to Polyurethane hose
1 Tee Piece Join 3mm Silicon hose to intake manifold
2 Small hose clamps Use on 3mm ID Silicon hose
500 mm 5mm ID Silicon hose Connect solenoid
4 Large hose clamps Use on 5mm ID Silicon hose
