IO-Link Parameters – Specific service PDU
Hans Turck GmbH & Co. KG | Witzlebenstraße 7, 45472 Mülheim/Ruhr, Germany | T +49 208 4952-0 | more@turck.com | www.turck.com
Index 0x62: Start and end value of the analog range
Transfer is executed according to the “big endian” specification.
Analog range start Analog range end
MSB LSB MSB LSB
0 1
The following values are allowed:
The end value must be at least 10 % f.s. above the start value:
AEP - ASP > 0x566
The start value of the analog range should not drop below the start value of the measuring
range:
ASP ≥ 0x0500
The end value of the analog range should not exceed the end value of the measuring range:
AEP ≤ 0x3AFF
Index 0x68: Offset
Transfer is executed according to the “big endian” specification.
Oset value
MSB LSB
0 1
The following values are allowed:
The offset (COF) can be ± 10 % of the measuring range. It is transferred with a sign bit.
-0x526 < COF < 0x526
Index 0x69: Maximum value memory
Formatting is implemented in compliance with the general representation of process values
(see above).
Index 0x6A: Minimum value memory
Formatting is implemented in compliance with the general representation of process values
(see above).
Index 0x70: Damping of the analog output
Transfer is executed according to the “big endian” specification.
Damping value
MSB LSB
0 1
Value (hexadecimal) Function
0x0000 0.00 s
0x0001 0.01 s
0x0002 0.02 s
… …
0x018F 3.99 s
0x0190 4.00 s
