TURFCO T3100 User Manual

3
85876 & 85877 RevA
TURFCO T3100 APPLICATOR
SPECIFICATIONS
Registered Trade Mark and Patents
US Patents 8,056,828 and 8,632,018 - Additional Patent Pending
TURFCO
®
is a registered trademarks of Turfco Manufacturing, Inc.
T3100™ and
VARI-RATE™ are trademarks of Turfco Manufacturing, Inc.
SPYKER, ACCUWAY, and BORDER PATROL trademarks of Spyker Spreaders, Brinly-Hardy, Inc.
DELAVAN
®
is a trademark of Delavan Pumps Inc. - AQUATEC™ is a trademark of AquaTec International, Inc.
BRIGGS AND STRATTON
®
is a registered trademark of Briggs and Stratton Corporation. Inc.
THE ENGINE EXHAUST FROM THIS PRODUCT CONTAINS CHEMICALS KNOWN TO THE STATE OF
CALIFORNIA TO CAUSE CANCER, BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM.
WARNING
Specications
Dimensions:
Width .......................................................... 35.5” Inches (0.90 Meter)
Height ......................................................... 50” Inches (1.27 Meter)
Length ........................................................ 65” Inches (1.65 Meter)
Weight Empty ................................................... 500 Pounds (227 Kg)
Weight Loaded
Spreader Full, Sprayer Tanks Empty .......... 675 Pounds (306 Kg) With Hopper Extension
Spreader Empty, Sprayer Tanks Full .......... 650 Pounds (294 Kg)
Spreader Full, Sprayer Tanks Full .............. 825 Pounds (374 Kg) With Hopper Extension
Operator Controls
Steering and Drive...........................Forward/Reverse Speed Control, Engine Throttle, Forward
Speed Control Pedal, Parking Brake and Freewheel Lever
Spreader..........................................Spreader Gate Open/Close, Vari-Rate Adjuster, Spinner
Speed Wide/Narrow, Trim Spread Border Control, Accuway
Spread Pattern Adjuster, and Gate Calibration Dial.
Sprayer ............................................Full Width On/Off, Trim Width On/Off, Spray
Gun On/Off, Spray Gun Flow Control, and
Spray Pressure Adjustment.
Production Rates
Spreading and/or Spraying..................4,000 Sq. Ft./Minute - 240,000 Sq. Ft./Hour
(371.6 Sq. Meters/Minute - 22,296 Sq. Meters/Hour)
Spreader Hopper Capacity ......................Approximately 2.9 Cubic Feet - 175 Pounds
(0.08 Cubic Meter - 79.4 Kg.) with Hopper Extension
Minimum/Maximum Spread Width
Full Spread .......................................... 16’ to 22’ Feet (5.49 to 6.7 Meter)
Trim Spread .........................................12’ to 14 Feet (3.66 to 4.27 Meter)
Sprayer Tank Capacity .............................18 US Gallons - 150 Pounds of Liquid (9 gallons per tank)
(68.1 Liter - 68.1 Kg)
Minimum/Maximum Spray Width
Full Spray ............................................9’ to 11’ Feet (2.74 to 3.35 Meter) 9’ Effective
Trim Spray ........................................... 3’ to 4’ Feet (0.91 to 1.22 Meter)
Engine ........................................................Briggs and Stratton INTEK 10.5 HP (7.8 kW), with 16 amp
Electric Voltage Regulator. Optional Electric Start Kit For
85876, Electric Start Standard For 85877.
Fuel Tank Capacity ................................... 2 Gallons (7.57 liters)
Transaxle ................................................... Variable Speed with Brake and Freewheel Control
Tires ........................................................ Front - 13 x 6.50-6 Rear - 18 x 6.50-8
Maximum Transport or Operating Ground Speed .......... 5 MPH (8.04 Km/h)
Turning (Steering) .............................................................. 9 Foot Circle (4.5 ft radius)
Maximum Slope Angle of Operation ............................... 15° Degrees
OPERATE ONLY IN AREAS WITH ADEQUATE VENTILATION. DO NOT OPERATE ENGINE IN ENCLOSED AREAS.
