Tuthill 2002 - Page 15

Manual 2017 Rev C p/n 2017
9
04
Description
MODEL
MAXIMUM
RPM
MAXIMUM
PRESSURE
DIFFERENTIAL*
MAXIMUM VACUUM*
MAXIMUM
TEMPERATURE
RISE*
MAWP
2002 5,275 12 psi (827 mbar) 16 inch-Hg (542 mbar) 225°F (125°C) 15 psi (1,034 bar)
2004 5,275 7 psi (483 mbar) 16 inch-Hg (542 mbar) 185°F (103°C) 15 psi (1,034 bar)
3002 3,600 15 psi (1,034 mbar) 16 inch-Hg (542 mbar) 210°F (117°C) 15 psi (1,034 bar)
3003 3,600 12 psi (827 mbar) 15 inch-Hg (508 mbar) 180°F (100°C) 15 psi (1,034 bar)
3006 3,600 7 psi (483 mbar) 15 inch-Hg (508 mbar) 170°F (94°C) 15 psi (1,034 bar)
4002 3,600 15 psi (1,034 mbar) 16 inch-Hg (542 mbar) 220°F (122°C) 17 psi (1,172 bar)
4005 3,600 10 psi (690 mbar) 16 inch-Hg (542 mbar) 210°F (117°C) 15 psi (1,034 bar)
4007 3,600 7 psi (483 mbar) 15 inch-Hg (508 mbar) 170°F (94°C) 15 psi (1,034 bar)
5003 2,850 15 psi (1,034 mbar) 16 inch-Hg (542 mbar) 195°F (108°C) 17 psi (1,172 bar)
5006 2,850 15 psi (1,034 mbar) 16 inch-Hg (542 mbar) 195°F (108°C) 15 psi (1,034 bar)
5009 2,850 7 psi (483 mbar) 15 inch-Hg (508 mbar) 160°F (89°C) 15 psi (1,034 bar)
6005 2,350 18 psi (1,241 mbar) 16 inch-Hg (542 mbar) 250°F (139°C) 18 psi (1,241 bar)
6008 2,350 14 psi (965 mbar) 16 inch-Hg (542 mbar) 240°F (133°C) 15 psi (1,034 bar)
6015 2,350 7 psi (483 mbar) 12 inch-Hg (406 mbar) 180°F (100°C) 15 psi (1,034 bar)
7006 2,050 15 psi (1,034 mbar) 16 inch-Hg (542 mbar) 235°F (131°C) 17 psi (1,172 bar)
7011 2,050 10 psi (690 mbar) 16 inch-Hg (542 mbar) 210°F (117°C) 15 psi (1,034 bar)
7018 2,050 6 psi (414 mbar) 12 inch-Hg (406 mbar) 120°F (67°C) 15 psi (1,034 bar)
* Maximum conditions based upon 70°F (21°C) inlet temperature and 14.7 psi (1 bar) absolute inlet pressure.
Table 4-2 – Maximum Operating Limits
