Manual 2017 Rev C p/n 2017
22
05
Installation
MOTOR AND ELECTRICAL
CONNECTIONS
WARNING
!
The motor and connections shall be protected
to assure that product and environmental
condensation does not come in contact with
the electrical connections.
It is the responsibility of the installer to assure
that the motor is in compliance with the latest
edition of IEC 60204-1 and all electrical
connections are performed per IEC 60204-1,
this includes overcurrent protection.
Wire the motor and other electrical devices, such
as solenoid valves and temperature switch, to the
proper voltage and amperage as indicated on the
nameplate of the component being wired. Turn
the blower by hand after wiring is completed to
determine that there are no obstructions and that
the blower turns freely. Then, momentarily start the
blower to check the direction of rotation. Figure
4-2 shows direction of airÀ ow in relation to rotor
rotation. The airÀ ow direction can be reversed by
reversing the appropriate motor leads.
