Tuthill 2002 - Lobe and Casing Clearances

Manual 2017 Rev C p/n 2017
40
10
MODEL
LOBES TO END PLATES
INTERLOBE
LOBE TO CASING
DRIVE END GEAR END TOTAL TIP-DOWEL TIP-PORT
2002
0.004 – 0.007 in.
(0.10 – 0.18 mm)
0.003 – 0.005 in.
(0.08 – 0.13 mm)
0.008 – 0.011 in.
(0.20 – 0.28 mm)
0.005 – 0.009 in.
(0.13 – 0.23 mm)
0.002 – 0.004 in.
(0.05 – 0.10 mm)
0.003 – 0.006 in.
(0.08 – 0.15 mm)
2004
0.004 – 0.007 in.
(0.10 – 0.18 mm)
0.003 – 0.005 in.
(0.08 – 0.13 mm)
0.008 – 0.011 in.
(0.20 – 0.28 mm)
0.005 – 0.009 in.
(0.13 – 0.23 mm)
0.002 – 0.004 in.
(0.05 – 0.10 mm)
0.003 – 0.006 in.
(0.08 – 0.15 mm)
3002
0.004 – 0.007 in.
(0.10 – 0.18 mm)
0.003 – 0.005 in.
(0.08 – 0.13 mm)
0.008 – 0.012 in.
(0.20 – 0.30 mm)
0.006 – 0.012 in.
(0.15 – 0.30 mm)
0.002 – 0.005 in.
(0.05 – 0.13 mm)
0.004 – 0.007 in.
(0.10 – 0.18 mm)
3003
0.005 – 0.008 in.
(0.13 – 0.20 mm)
0.003 – 0.005 in.
(0.08 – 0.13 mm)
0.009 – 0.012 in.
(0.23 – 0.30 mm)
0.010 – 0.014 in.
(0.25 – 0.36 mm)
0.002 – 0.005 in.
(0.05 – 0.13 mm)
0.004 – 0.007 in.
(0.10 – 0.18 mm)
3006
0.006 – 0.010 in.
(0.15 – 0.25 mm)
0.003 – 0.005 in.
(0.08 – 0.13 mm)
0.010 – 0.013 in.
(0.25 – 0.33 mm)
0.010 – 0.014 in.
(0.25 – 0.36 mm)
0.002 – 0.005 in.
(0.05 – 0.13 mm)
0.004 – 0.007 in.
(0.10 – 0.18 mm)
4002
0.004 – 0.009 in.
(0.10 – 0.23 mm)
0.004 – 0.006 in.
(0.10 – 0.15 mm)
0.009 – 0.013 in.
(0.23 – 0.33 mm)
0.012 – 0.016 in.
(0.30 – 0.41 mm)
0.003 – 0.006 in.
(0.08 – 0.15 mm)
0.005 – 0.008 in.
(0.13 – 0.20 mm)
4005
0.005 – 0.010 in.
(0.12 – 0.25 mm)
0.004 – 0.006 in.
(0.10 – 0.15 mm)
0.010 – 0.014 in.
(0.25 – 0.36 mm)
0.012 – 0.016 in.
(0.30 – 0.41 mm)
0.003 – 0.006 in.
(0.08 – 0.15 mm)
0.005 – 0.008 in.
(0.13 – 0.20 mm)
4007
0.005 – 0.010 in.
(0.12 – 0.25 mm)
0.004 – 0.006 in.
(0.10 – 0.15 mm)
0.010 – 0.014 in.
(0.25 – 0.36 mm)
0.012 – 0.016 in.
(0.30 – 0.41 mm)
0.003 – 0.006 in.
(0.08 – 0.15 mm)
0.005 – 0.008 in.
(0.13 – 0.20 mm)
5003
0.004 – 0.009 in.
(0.10 – 0.23 mm)
0.004 – 0.006 in.
(0.10 – 0.15 mm)
0.009 - 0.013 in.
(0.29 - 0.33 mm)
0.014 – 0.018 in.
(0.36 – 0.46 mm)
0.003 – 0.006 in.
(0.08 – 0.15 mm)
0.005 – 0.008 in.
(0.13 – 0.20 mm)
5006
0.005 – 0.010 in.
(0.13 – 0.25 mm)
0.004 – 0.006 in.
(0.10 – 0.15 mm)
0.010 – 0.014 in.
(0.25 – 0.36 mm)
0.014 – 0.018 in.
(0.36 – 0.46 mm)
0.003 – 0.006 in.
(0.08 – 0.15 mm)
.005 – .008 in.
(0.13 – 0.20 mm)
5009
0.005 – 0.010 in.
(0.13 – 0.25 mm)
0.004 – 0.006 in.
(0.10 – 0.15 mm)
0.010 – 0.014 in.
(0.25 – 0.36 mm)
0.014 – 0.018 in.
(0.36 – 0.46 mm)
0.003 – 0.006 in.
(0.08 – 0.15 mm)
0.005 – 0.008 in.
(0.13 – 0.20 mm)
6005
0.008 – 0.013 in.
0.20 – 0.33 mm)
0.005 – 0.007 in.
(0.12 – 0.18 mm)
0.015 – 0.019 in.
(0.38 – 0.48 mm)
0.010 – 0.014 in.
(0.25 – 0.36 mm)
0.004 – 0.007 in.
(0.10 – 0.18 mm)
0.006 – 0.009 in.
(0.15 – 0.23 mm)
6008
0.008 - 0.013 in.
(0.20 - 0.33 mm)
0.005 – 0.007 in.
(0.12 – 0.18 mm)
0.015 – 0.019 in.
(0.38 – 0.48 mm)
0.010 – 0.014 in.
(0.25 – 0.36 mm)
0.004 – 0.007 in.
(0.10 – 0.18 mm)
0.006 – 0.009 in.
(0.15 – 0.23 mm)
6015
0.009 – 0.014 in.
(0.23 – 0.36 mm)
0.005 – 0.007 in.
(0.13 – 0.18 mm)
0.016 – 0.020 in.
(0.40 – 0.50 mm)
0.010 – 0.014 in.
(0.25 – 0.36 mm)
0.004 – 0.007 in.
(0.10 – 0.18 mm)
0.006 – 0.009 in.
(0.15 – 0.23 mm)
7006
0.008 – 0.012 in.
(0.20 – 0.30 mm)
0.005 – 0.007 in.
(0.13 – 0.18 mm)
0.015 – 0.018 in.
(0.38 – 0.46 mm)
0.012 – 0.016 in.
(0.30 – 0.41 mm)
0.004 – 0.007 in.
(0.10 – 0.18 mm)
0.006 – 0.009 in.
(0.15 – 0.23 mm)
7011
0.010 – 0.014 in.
(0.25 – 0.36 mm)
0.005 – 0.007 in.
(0.13 – 0.18 mm)
0.017 – 0.020 in.
(0.43 – 0.51 mm)
0.012 – 0.016 in.
(0.30 – 0.41 mm)
0.004 – 0.007 in.
(0.10 – 0.18 mm)
0.006 – 0.009 in.
(0.15 – 0.23 mm)
7018
0.010 – 0.014 in.
(0.25 – 0.36 mm)
0.005 – 0.007 in.
(0.13 – 0.18 mm)
0.017 – 0.020 in.
(0.43 – 0.51 mm)
0.012 – 0.016 in.
(0.30 – 0.41 mm)
0.004 – 0.007 in.
(0.10 – 0.18 mm)
0.006 – 0.009 in.
(0.15 – 0.23 mm)
ASSEMBLY CLEARANCES
