Manual 1808 Rev B p/n 001808 0000
25
GENERAL
The graphics on the following pages and their parts
lists cover all parts in the KD-30 and KD-50 pumps,
any of which are available as spare parts. Always
include the model and serial number of the pump
when ordering parts.
SPARE PARTS
Recommended spare parts are indicated on the
parts list by an asterisk, which include gaskets,
O-rings, shaft seal, and discharge valves. The
recommended spare parts are intended to support
the pump until a more extensive stock of spare
parts can be developed based upon usage data
as parts are replaced. The number of pumps in
operation plus the degree of importance of keeping
the pumps in ready condition are factors to be
considered when developing a stock of spare
parts. Maintain an adequate supply of AX Oil and
Loctite 515, and have a vacuum gauge available
for checking pump performance.
10
REPLACEMENT PARTS
