TV Logic LVM-171S User Manual

18 Multi Format LCD Monitor
● KEY LED
- Used to control the Key Lamp on the front of
the monitor.
● F1 / F2 / F3 KEY MAPPING
- User can select the function for the F1 / F2 /
F3 button.
- Selectable functions: ASPECT, H/V DELAY,
FREEZE, WAVEFORM, TIMECODE, CC SEL,
ALM SEL, OUTPUT MODE, FAST MODE,
FILTER, FORCE Psf, UMD, COLOR TEMP and
BLUE ONLY.
● KEY LOCK
- This item locks all buttons except Power,
Source and Menu buttons.
● WAVE FORM DISPLAY
- This function sets the Waveform. Available
options are di erent according to the Input
signal.
- YCbCr: O / Waveform / Vector Scope /
Waveform Wide / Waveform YCbCr /
Wave_Vector / Vector_YCbCr / Full
Waveform(Y) / Full Vector Scope.
● WAVE FORM INTENSITY
- Controls the brightness of the Waveform/
Vector display.
- Available values are between 1 ~ 63. The hig
her the number the brighter the waveform
will be.
● WAVE FORM TRANS
- Controls the transparency level of the
Waveform/Vector.
- Available values are OPAQUE and TRANS.
• If the main OSD overlaps with the
Waveform/Vector when the option us set
to OPAQUE, it will automatically display it as
transparent and change back to opaque
when the main OSD disappears.
[6] FUNCTION KEY [7] WAVEFORM & FOCUS
5. Menu Operations
