TV Logic LVM-171S User Manual

Multi Format LCD Monitor 23
● PBP(PIP) Mode Select
- Use the PBP button to change into PBP Screen. Available modes are as shown below.
• In order to avoid confusion of terms, the PIP mode on the screen is collectively referred to as PBP.
● Screen Select
- In PBP mode, use the [F1] button to select the desired display then control the desired function.
- Selected display will be highlighted.
[1] PBP(Picture-by-Picture) / PIP(Picture-in-Picture)
6. Button Function
<PBP>
<Screen-1 Selected>
<Screen-2 Selected>
<1:1(FULL PICTURE> <PIP>
