TV Logic LVM-171S User Manual

Multi Format LCD Monitor 7
3. Controls & Functions
LVM-171S : FRONT
LVM-171S : REAR
POWER
SOURCE
SCAN
ASPECT
MARKER
FUNCTION/
FUNCTION SELECT
MENU/EXIT
KNOB(UP/DOWN/ENTER)
USB(Firmware Update)
AUDIO OUT
AUDIO-IN
AC IN
POWER S/W
DC IN
RS-422 IN
RS-422 OUT
REMOTE
LAN
CVBS1/Y/G/S-Y OUT
CVBS3/PR/R/S-C IN
CVBS2/Pb/B OU T
HDMI IN
CVBS2/Pb/B IN
CVBS1/Y/G/S-Y IN
SDI-A IN
SDI-B IN
CVBS3/Pr/R/S-C OUT
SDI-A OUT
DVI-I(w/HDCP) IN
SDI-B OUT
