TV Logic LVM-171S User Manual

24 Multi Format LCD Monitor
- Adjust the ratio using the Knob.
- Control range for width: 0~1920.
- Control range for height : 0~1080.
- The size-adjusted picture always stays in the
center of the screen.
- The aspect ratio can be speci ed within the
screen size supported by the monitor.
- The size can be adjustable with 2 increment
and decrement.
● Used to adjust the Width /Height display
ratio.
1. Press the [ASPECT] button on the front of
the monitor to acticate the [USER ASPECT]
mode.
2. After the activation, press the Knob to
begin controlling. Adjust the ratio using the
Knob.
[2] USER Aspect
6. Button Function
USER ASPECT
WIDTH +1920
HEIGHT +1080

TV Logic LVM-171S Specifications

General

Brand	TV Logic
Model	LVM-171S
Category	Monitor
Language	English
