10 4K LCD Monitor
● [REMOTE] (RJ-45)
- Provides connection to control
equipment(parallel switch) for external
monitor control.
- Features can be changed in the GPI section of
the OSD menu.
● [RS422 IN/OUT] (RJ-45)
- Used to control the monitor with a protocol
provided by TVLogic.
● [HDMI]
- Signal input terminal for HDMI signal.
● [SDI-A,B,C,D] (BNC)
- SDI signal input terminal for SDI A,B,C,D
signal.
● [AUDIO IN]
- Used to connect the audio input signal.
● [LAN]
- Used to control the monitor with a protocol
provided by TVLogic.
● ~ AC IN
- 100 ~ 240V AC 50/60Hz
<WARNING!!>
When using the product make sure
to ground, whenever possible, before
connecting the input signal cable in order to
prevent any possible damage to the product
or connected devices. The damage may
include signal noise, malfunction of main
board or display panel. And the connected
devices such as camera or video source
player may also be inuenced through signal
cable. Please check if the AC power source
and the power extender or power distributor
is grounded.
LUM-242G : REAR
3. Controls & Functions
