TVLogic LUM-242G User Manual

18 4K LCD Monitor
REM
O
TE (
R
J
-45
)
1:
P
in1
2
:
P
in2
3:
P
i
n
3
4:
P
in4
5: P
i
n5
6:
P
i
n
6
7:
P
in7
8
:
G
ND
1
8
Menu
Classi-
cation
Settable Values
PIN
1~6
NONE
SINGLE-SDI
2SI-SDI
QUAD-SDI
HDMI
ASPECT
H/ V DELAY
BLUE ONLY
MONO
16:9 MARKER
4:3 MARKER
4:3 ON AIR MARKER
15:9 MARKER
14:9 MARKER
13:9 MARKER
1.85:1 MARKER
2.35:1 MARKER
1.85:1&4:3 MARKER
CENTER MARKER
SAFETY AREA 80%
SAFETY AREA 85%
SAFETY AREA 88%
SAFETY AREA 90%
SAFETY AERA 90%
SAFETY AERA 93%
SAFETY AERA 100%
TALLY R
TALLY G
[3] GPI
5. Menu Operations
● This item activates/ inactivates the
REMOTE function.
● The user may designate a function for
each pin and each pin’s default setting is
as follows.
● The default settings are as follows:
PIN 1 : SINGLE-SDI
PIN 2 : 2SI-SDI
PIN 3 : QUAD-SDI
PIN 4 : HDMI
PIN 5 : ASPECT
PIN 6 : H/V Delay
PIN 7 is POWER ON/OFF use only, PIN 8 is GND
