TVLogic LUM-242G User Manual

30 4K LCD Monitor
7. Product Specications
* The specication above may be changed without notice.
LUM-242G
LCD
Size 23.8”
Resolution 3840 X 2160 (16:9)
Pixel Pitch 0.13725(H) X 0.13725(V) mm
Color Depth 1.07B Colors (A-FTC 10bit)
Viewing Angle H : 178 degrees / V : 178 degrees
Luminance of white 540 cd/ m
2
(Center)
Contrast Ratio 1200 : 1
Display Area 527.04(H) X 296.46(V) mm
Input Connector
1 X HDMI HDMI Input
4 X BNC 12G-SDI A/B, 3G-SDI C/D Channel Input
Output 4 X BNC 12G-SDI A/B, 3G-SDI C/D Channel (Active Through Out)
Input Signal
12G-SDI 12Gb/s
6G-SDI 6Gb/s
3G-SDI 2.970Gb/s
HD-SDI 1.485Gbps
HDMI 480p/720p/1080p/2160P
SDI Input Signal
Formats
SMPTE-425M-A/B
1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
1080i(60/59.94/50)
SMPTE-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE-296M 720p (60/59.94/50)
SMPTE-260M 1035i (60/59.94)
SMPTE-125M 480i (59.94)
ITU-R BT.656 576i (50)
SMPTE ST 2036-1:2009 3840×2160(23.98/24/25/29.97/30/50/59.94/60p)
SMPTE ST 2048-2:2011 2048x1080(23,98/24/25/29.97/30p/psf, 47.95/48/50/59.94/60p)
SMPTE ST 2081 3840x2160 (30/25/24p)
SMPTE ST 2082 3840x2160 (60/50/30/25/24p)
Audio In Embedded Audio / Analog Stereo (Phone Jack)
Audio Out Internal Speaker (Stereo) / Analog Stereo (Phone Jack)
Power DC 24V / AC100~240V(50~60Hz)
Power Consumption (Approx.) 115 Watts(Ma x )
Operating Temperature
0℃ to 35℃ (32
℉
to 95
℉
)
Storage Temperature
-20℃ to 60℃ (-4
℉
to 140
℉
)
Main Body Dimensions (mm/inch) 552.48 x 360.4 x 95.9 (21.75 x 14.18 x 3.77)
Main Body Dimensions with stand (mm/inch) 586.13 x 388.2 x 150 (23.07 x 15.28 x 5.90)
Box Dimensions (mm/inch) 555 X 450 X 280 (21.85 X 17.72 X 11.02)
Weight 10.5kg / 23.14lbs
Basic Accessories AC Power Cord, Stand
Optional Accessories Rack Mountable Kit, ND Filter, Carrying Case, V-mount, G-mount
