TVLogic LUM-242G User Manual

8 4K LCD Monitor
FRONT
3. Controls & Functions
● [HDMI] Button/Lamp
- Used to select HDMI input.
● [SINGLE-SDI] Button/Lamp
- Used to select SDI input for one channel.
Previously selected SDI input selection
displays.
- Press the button to move through the modes:
SDI-A -> SDI-B -> SDI-C -> SDI-D
● [2SI-SDI] Button/Lamp
- Used to select 2-SAMPLE INT-SDI input signal.
- Press the button to move through the modes:
2SI(4CH)->2SI(2CH)
● [QUAD-SDI] Button/Lamp
- Used to select QUAD-SDI input signal.
● [F1 ~ F5] Button/Lamp
- Shortcut key for KEY MAPPING feature in the
OSD MENU.
- Selectable options are as follows :
1) BLUE ONLY
- Activates in the order: BLUE ONLY – MONO.
- BLUE ONLY : Used to remove red and green
from the input signal and display the screen
only under a blue signal.
- MONO : Used to remove all colors from the
input signal and display the screen only
under white and black signal.
2) H/V DELAY,
- Used to check horizontal and vertical sync.
simultaneously by moving the screen up/
down/left/right.
- In this mode, the brightness of image
automatically increase for easy verication
of synchronized signals.
3) COLOR TEMP
- Used to controls the color temperature
and allows instant access to preset the color
temperature settings.
4) AUDIO LVM
- Used to activate/deactivate the Audio Level
Meter.
5) TIME CODE
- Used to activate/deactivate the Time Code.
6) LUMA ZONE
- Used to activate/deactivate the Luma Zone
function.
