16 • Function description OptiSelect manual powder gun
- Modify the powder output (press the + or - key on the gun).
The powder output will be increased or decreased accord-
ingly. The keys only change the value of powder output (in%)
- Change application modes (Preset and Program Mode) by
pressing the + and - keys on the gun at the same time. The
change takes place counterclockwise. Check by observing
the key LEDs on the control unit
Note:
By pressing one of the keys, the preset values will be displayed
versus the actual values!
Spray nozzles
Standard-Set
Nozzle 150 mm
(not part of the standard set, available separately, see spare parts
list)
Nozzle 300 mm
not shown (not part of the standard set, available separately, see
spare parts list)
Flat jet nozzle with
vented central
electrode
Round jet nozzle with
deflector and vented
central electrode
Extended flat jet nozzle
with vented central
electrode
Extended round jet nozzle
with vented deflector and
vented central electrode
