TW Gema OptiSelect - Optiselect Manual Powder Gun - Nozzle Combinations

V 07/07
OptiSelect manual powder gun Spare parts list • 39
OptiSelect manual powder gun - nozzle combinations
Nozzle set - flat jet, NF08, pos. 1, 2 1000 047#
Nozzle set - round jet, pos. 5, 6, 9 382 922
1 Electrode holder (flat jet nozzle) 1000 055#
2 Flat jet nozzle 1000 049#
3 Threaded sleeve 1000 948
5 O-ring - Ø 5x1 mm 231 606#
6 Round jet nozzle 378 518#
7 Deflector - Ø 16 mm 331 341#
7.1 Deflector - Ø 24 mm 331 333#
7.2 Deflector - Ø 32 mm 331 325#
8 Extension - 150 mm 378 852#
8.1 Extension - 300 mm 378 860#
9 Electrode holder, incl. pos. 5 (round jet nozzle-central electrode) 382 914#
# Wearing part
321
95
67
8
OptiSelect manual powder gun - nozzle combinations
