36 • Spare parts list OptiSelect manual powder gun
OptiSelect manual powder gun - spare parts list
Remarks
1. If a part of the gun body should be broken, or the high voltage
cascade in the gun body should be defective, then the whole gun
body is to be sent in for repair and check!
2. If the powder gun cable is defective, it is to be completely sent in
for repair!
A
OptiSelect manual powder gun - complete
negative polarity, incl. gun cable - 6 m, rinsing air hose - 6 m, flat jet nozzle, brush
and parts kit, without powder hose
1002 100
OptiSelect manual powder gun - complete
positive polarity, incl. gun cable - 6 m, rinsing air hose - 6 m, flat jet nozzle, brush
and parts kit, without powder hose
1002 101
B
OptiSelect manual powder gun shaft (incl. cascade)
Negative polarity (-)
1001 891
Positive polarity (+)
1001 892
C
Cascade (negative polarity) - complete
1000 809
Cascade (positive polarity) - complete
1002 031
1
Gun body
1001 155
Handle - complete set (pos. 5, 6, 7 and 8) 1000 807
2
Trigger - complete (incl. pos. 2 and 3)
1001 341
3 Compression spring - 0.36x4.2x49.4 mm 1001 487
4 Trigger cover 1000 801
5 Grasp termination 1000 806
6 Radial gasket 1000 803
7 Gun cable - L=6 m, complete 1001 528
Extension cable for gun cable - L=6m, incl. safety clamp 1002 161
Extension cable for gun cable - L=14m, incl. safety clamp 1002 162
Safety clamp for extension cable 1002 064
8 Grub screw - M3x8 mm 1000 844
10 Powder tube - complete 1001 339
10.2 O-ring - Ø 12x1.5 mm 1000 822
11 Rinsing air connection 1000 804
12 Clip ring 1000 898
13 Compression spring 1001 488
