V 07/07
OptiSelect manual powder gun Maintenance and cleaning • 29
Dismantling the gun
The gun should only be dismantled when this is made necessary by a de-
fect or contamination. It is only to be dismantled so far, as the desired
part is accessible.
Attention:
The control unit must be switched off and the gun plug detached,
before cleaning the gun!
If the cascade is defective or the shaft is broken, send the complete
shaft to an authorized ITW Gema service center!
Dismantling the gun
1. 2.
3.
4.
5.
6.
7.
8.
