TWR Lighting E-2/3DB User Manual

E-2/3DB CONTROLLER
E:\Documents and Settings\Administrator\Local Settings\Temporary Internet Files\OLK3\E2-3DB.doc
Rev. 01/13/00; Rev. 07/2000 o2L/H
Rev. 10/2000 (dwgs. 100239, 601, 601-01, 601-02, H02-258, 100031, 279L, 274S, 100089)
Rev. 06/21/00 (Reformatted Text; Revised Pg. 3 (2.4.1, 20 amp to 30 amp)
Pg. 27
6.0 MAJOR COMPONENTS LIST (continued)
SCHEMATIC
TAG #
DESCRIPTION PART NUMBER
M1, M2 CURRENT SENSOR SRCR430T
MOV2 METAL OXIDE VARISTOR MOV524V15
MOVMOD1, 2, 3,
4
SURGE SUPPRESSOR DTK-120HW
MOV 2, 3, 4, 5, 6,
MOV 7
METAL OXIDE VARISTOR V1000LA80A
P1, J1 15 POSITION PLUG STT60009
P2 12 POSITION PLUG STT60019
PCB #1 E-2/3DB CONTROL PCB STH01279
PCB #2
HIGH VOLTAGE RECTIFIER PCB
STH02258A
PCB #3 RELAY PCB STH03279
PCB #4
TRIGGER VOLTAGE RECTIFIER
PCB
STH04269
PHOTOCELL 120V AC PHOTOCELL P2455L
R31A, R31B,
R31C
50 ohm 225W STA22004
R32A, R32B,
R32C
25K ohm 20W STA08020
R33A, R33B,
R33C
2.4 MEG 2W ST08010
SL1, SL2 5 amp FUSE KTK5
SW1, SW2 SPDT 10 amp SWITCH STJ01002
T2 FERRORESONANT
TRANSFORMER
STC30019
T2A FERRORESONANT
TRANSFORMER
STC30020
T1 ISOLATION TRANSFORMER 100272
