E-2/3DB CONTROLLER
E:\Documents and Settings\Administrator\Local Settings\Temporary Internet Files\OLK3\E2-3DB.doc
Rev. 01/13/00; Rev. 07/2000 o2L/H
Rev. 10/2000 (dwgs. 100239, 601, 601-01, 601-02, H02-258, 100031, 279L, 274S, 100089)
Rev. 06/21/00 (Reformatted Text; Revised Pg. 3 (2.4.1, 20 amp to 30 amp)
Pg. 1
1.0 INTRODUCTION
TWR Lighting, Inc.’s Model E-2/3DB Type L-864/L-865 Controller has been
designed and built to the Federal Aviation Advisory Circular 150/5345-43E with
safety and reliability in mind. TWR is committed to providing our customers with
some of the best products and services available. TWR welcomes you to our family
of fine products and we look forward to servicing your needs now and in the future.
NOTE: Structures exceeding 500’ will require to be painted, in addition to this
lighting, for added visual hazard marking.
1.1 APPLICATION
The E-2/3DB Controller is for use on lighting structures or towers 351' to
700' AGL (above ground level) that are approved to be lighted with Dual
White/Red Flashing Medium Intensity Strobes in accordance with the FAA
Advisory Circular 70/7460-1J.
1.2 SPECIFICATIONS OF EQUIPMENT
Dimensions:
Controller (H x W x D)/Weight 33.00" x 36.75" x 9.0"/210.0 lbs.
Mounting Dim (H x W) 37.375” x 24.0”
Beacon Height/Weight 28.0” /36 lbs.
Cable Diameter/Weight per 100 ft. 625” +/- 10% 24 lbs.
Electrical Voltage: 120V AC +/- 10% 60 Hz (Standard)
240V AC +/- 10% 60 Hz (Available)
Intensity:
White Daymode 20,000 +/- 25% Effective Candelas
Red Nightmode 2,000 +/- 25% Effective Candelas
White Nightmode (Back-up mode) 2,000 +/- 25% Effective Candelas
Beam Spread:
Horizontal 360°
Vertical 3° Minimum
Flash Rate:
White Daymode 40 fpm +/- 2 fpm
Red Nightmode 22 fpm +/- 2 fpm
White Nightmode (Back-up mode) 40 fpm +/- 2 fpm
Wattage:
Daymode 285 Watts
Red Nightmode 930 Watts
White Nightmode 105 Watts
Temperature: +55°C / -55°C
Beacon Wind Load: 2.1 ft
2
