E-2/3DB CONTROLLER
E:\Documents and Settings\Administrator\Local Settings\Temporary Internet Files\OLK3\E2-3DB.doc
Rev. 01/13/00; Rev. 07/2000 o2L/H
Rev. 10/2000 (dwgs. 100239, 601, 601-01, 601-02, H02-258, 100031, 279L, 274S, 100089)
Rev. 06/21/00 (Reformatted Text; Revised Pg. 3 (2.4.1, 20 amp to 30 amp)
Pg. 5
2.5.1.3 Slip the electrical cable for the dual beacon through the
watertight connector (cable gland bushing) and tighten the
gland nut to make a watertight seal. Attach the wires to the
terminal strip as follows:
Wire color
to
match
Lamp platform
wire color
Terminal
Block No.
10 Gauge Black 12 Gauge Black 1
10 Gauge Red/Black 20 Gauge Red/Black 2
10 Gauge Red 20 Gauge Red/White 3
14 Gauge White 20 Gauge White 4
14 Gauge White/Green
20 Gauge White/Green
5
14 Gauge Green 20 Gauge Green 6
16 Gauge Blue 20 Gauge Blue 7
16 Gauge Brown 20 Gauge Brown 8
16 Gauge Bare Wire Beacon Base
2.5.2 LIGHTING KIT WIRING
Install wiring between the controller to the beacon utilizing either
strobe cable or conduit method. Refer to Drawings HDO-279, 601,
601-01, and 601-02, for installation of light kits. Following these
minimum guidelines as well as any local or end user addition
requirements, installing light kits will require lifting of the cable by the
supplied cable grip or conduit to affix to the tower. Always work
safely and adhere to all OSHA Safety Guidelines when lifting wiring
or working on the structure or tower itself. It is the installer’s
responsibility to install the lighting kit in a safe manner. Installers can
request from OSHA their requirements 29CFT 1926.21, and 29CFR
1926.105 to ensure compliance to regulations.
NOTE: On occasion, a set of custom lighting kit drawings may
be specifically requested by a customer and installed in this
manual. In cases such as this, the drawings will proceed the
manual if a conflict occurs.
All the necessary information for wiring the dual beacon and
sidelights is contained on the tower kit Drawings 601, 601-01, and
601-02. The connections for the dual beacon and sidelights in the
controller are as follows:
