E-2/3DB CONTROLLER
E:\Documents and Settings\Administrator\Local Settings\Temporary Internet Files\OLK3\E2-3DB.doc
Rev. 01/13/00; Rev. 07/2000 o2L/H
Rev. 10/2000 (dwgs. 100239, 601, 601-01, 601-02, H02-258, 100031, 279L, 274S, 100089)
Rev. 06/21/00 (Reformatted Text; Revised Pg. 3 (2.4.1, 20 amp to 30 amp)
Pg. 2
2.0 INSTALLATION
WARNING - DANGER!!
THIS SYSTEM OPERATES AT HIGH VOLTAGE LEVELS THAT COULD BE
LETHAL TO SERVICE PERSONNEL. ALL INSTALLATION AND MAINTENANCE
WORK SHOULD BE DONE BY QUALIFIED SERVICE PERSONNEL ONLY.
WHEN PERSONNEL IS INSTALLING SYSTEM OR PERFORMING
MAINTENANCE ON THIS SYSTEM, MAKE SURE THE POWER IS TURNED OFF
AT THE SERVICE BREAKER PANEL!!
READ AND UNDERSTAND THE THEORY OF OPERATION AND ITS SAFETY
MESSAGES BEFORE ATTEMPTING INSTALLATION/MAINTENANCE OF THIS
SYSTEM. DO NOT ATTEMPT TO DEFEAT THE INTERNAL SAFETY SWITCHES
IN THE CONTROLLER AND BEACONS!!
2.1 POWER SUPPLY CONTROL CABINET MOUNTING
The power supply control cabinet can be located at the base of the structure
or in an equipment building. Mounting Dimensions can be found in Section
1.2 on page 5. Pay particular attention when choosing your controller
mounting location to ensure proper door opening and room for service
personnel. Refer to installation Drawings INS-279 and HDO-279 for ease of
install.
2.2 PHOTOCELL HOUSING
The standard photocell housing is supplied with a 20’ pigtail of 16 AWG
TYPE TFFN wire. On occasion, in mounting of the photocell, an additional
amount of wire may be required. Refer to Drawing 100239 for proper
assistance on determining gauge of wire for your specific needs.
2.3 PHOTOCELL WIRING
(Refer to Drawings HDO-269 and H40-279)
If the control cabinet is mounted inside an equipment building, the photocell
should be mounted vertically on ½” conduit outside the building above the
eaves facing north. Wiring from the photocell housing socket to the control
cabinet should consist of one (1) each; red, black, and white wires. The
white wire is connected to the socket terminal marked "COM," the black wire
is connected to the socket terminal marked "B," and the red wire is
