TWR Lighting E-2/3DB User Manual

E-2/3DB CONTROLLER
E:\Documents and Settings\Administrator\Local Settings\Temporary Internet Files\OLK3\E2-3DB.doc
Rev. 01/13/00; Rev. 07/2000 o2L/H
Rev. 10/2000 (dwgs. 100239, 601, 601-01, 601-02, H02-258, 100031, 279L, 274S, 100089)
Rev. 06/21/00 (Reformatted Text; Revised Pg. 3 (2.4.1, 20 amp to 30 amp)
Pg. 28
6.0 MAJOR COMPONENTS LIST (continued)
SCHEMATIC TAG
#
DESCRIPTION PART NUMBER
T3A, T3B, T3C BURSTING CHOKE 100273
T4, T5, T6, T7,
T8, T9
TRIGGER TRANSFORMER STC05005
TB1 17 PART TERM BLK TERMBLK-17
TB2 7 PARK TERM BLK TERMBLK141-7
TB3 12 PART TERM BLK TERMBLK 141-12
TB5 3 PART TERM BLK CURBLK
TLS1
THERMAL LIMITING SWITCH/210
STJ10008
TLS2
THERMAL LIMITING SWITCH/130
STJ10010
TB4 4 PART TERM BLK TERMBLK141-4
J2 6 POSITION PLUG STT60017
J3 18 POSITION PLUG STT60015
FLASHTUBE SOCKET 100319
HINGE GASKET STBEAGSKT
LENS GASKET STBEAGSKT2
CLEAR LENS STDBCLENS
DB STROBE BEACON FIXTURE STDBEACON
STROBE BEACON CABLE STROBCABLE-3
SIDELIGHT CABLE STCABLEOB
FAN PLUG CD045-36
VENT FILTER STFILTER
