2.5 TOWER LIGHTING KIT
When installing this system, the customer will need to choose between using
strobe cable or conventional conduit wiring methods to wire the strobe
beacons. Refer to Lighting Kit Drawings 601-01 and 601-02 for conduit, and
601 for cable installations.
WARNING DANGER!!!
THIS SYSTEM OPERATES AT HIGH VOLTAGE LEVELS THAT COULD BE
LETHAL TO SERVICE PERSONNEL. ALL INSTALLATION AND MAINTENANCE
WORK SHOULD BE DONE BY QUALIFIED SERVICE PERSONNEL ONLY. WHEN
PERSONNEL IS INSTALLING SYSTEM OR PERFORMING MAINTENANCE ON
THIS SYSTEM, MAKE SURE THE POWER IS TURNED OFF AT THE SERVICE
BREAKER PANEL!!
READ AND UNDERSTAND THE THEORY OF OPERATION AND ITS SAFETY
MESSAGES BEFORE ATTEMPTING INSTALLATION/ MAINTENANCE OF THIS
SYSTEM. DO NOT ATTEMPT TO DEFEAT THE INTERNAL SAFETY SWITCHES
IN THE CONTROLLER AND BEACONS!!
2.5.1 Beacon Mounting and Wiring
(Refer to Drawings HDO-279 and INS-279)
2.5.1.1 Bolt the beacon to the mounting plate using four 5/8” x 1-
1/4” galvanized bolts that are supplied. Installer should
make sure to check for full thread engagement on Anco
locknut. Allow 16” clearance in back of the hinge (25” from
the center of the base) to tilt lens back without hitting an
obstruction.
2.5.1.2 Level the beacon using the spirit level at the base of the
lens. Shims may be used under beacon base or triple
nutting each bolt with palnuts on all four (4) nuts.
