E-2/3DB CONTROLLER
E:\Documents and Settings\Administrator\Local Settings\Temporary Internet Files\OLK3\E2-3DB.doc
Rev. 01/13/00; Rev. 07/2000 o2L/H
Rev. 10/2000 (dwgs. 100239, 601, 601-01, 601-02, H02-258, 100031, 279L, 274S, 100089)
Rev. 06/21/00 (Reformatted Text; Revised Pg. 3 (2.4.1, 20 amp to 30 amp)
Pg. 6
2.5.2.1 Connect the 10 gauge Red/Black wire from Beacon #1
wiring to TB1-1.
2.5.2.2 Connect the 10 gauge Red wire from Beacon #1 wiring to
TB1-2.
2.5.2.3 Connect the 10 gauge Black wire from Beacon #1 wiring to
TB1-3.
2.5.2.4 Connect the 14 gauge White wire from Beacon #1 wiring to
TB1-4.
2.5.2.5 Connect the 14 gauge White/Green wire from Beacon #1
wiring to TB1-5.
2.5.2.6 Connect the 10 gauge Red/Black wire from Beacon #2
wiring to TB1-6.
2.5.2.7 Connect the 10 gauge Red wire from Beacon #2 wiring to
TB1-7.
2.5.2.8 Connect the 10 gauge Black wire from Beacon #2 wiring to
TB1-8.
2.5.2.9 Connect the 14 gauge White wire from Beacon #2 wiring to
TB1-9.
2.5.2.10 Connect the 14 gauge White/Green wire from Beacon #2
wiring to TB1-10.
2.5.2.11 Connect the 10 gauge Red/Black wire from Beacon #3
wiring to TB1-11.
2.5.2.12 Connect the 10 gauge Red wire from Beacon #3 wiring to
TB1-12.
2.5.2.13 Connect the 10 gauge Black wire from Beacon #3 wiring to
TB1-13.
2.5.2.14 Connect the 14 gauge White wire from Beacon #3 wiring to
TB1-14.
2.5.2.15 Connect the 14 gauge White/Green wire from Beacon #3
wiring to TB1-15.
