E-2/3DB CONTROLLER
E:\Documents and Settings\Administrator\Local Settings\Temporary Internet Files\OLK3\E2-3DB.doc
Rev. 01/13/00; Rev. 07/2000 o2L/H
Rev. 10/2000 (dwgs. 100239, 601, 601-01, 601-02, H02-258, 100031, 279L, 274S, 100089)
Rev. 06/21/00 (Reformatted Text; Revised Pg. 3 (2.4.1, 20 amp to 30 amp)
Pg. 7
2.5.2.16 Connect the 14 gauge Green wire from Beacon #1 to the
first ground lug located to the left of TB1.
2.5.2.17 Connect the 14 gauge Green wire from Beacon #2 to the
first lug located to the left of TB1.
2.5.2.18 Connect the 14 gauge Green wire from Beacon #3 to the
first lug located to the left of TB1.
2.5.2.19 Connect the 16 gauge Bare Drain wire (if strobe cable
install) from Beacon #1 to second ground lug located to the
left of TB1.
2.5.2.20 Connect the 16 gauge Bare Drain wire (if strobe cable
install) from Beacon #2 to second ground lug located to the
left of TB1.
2.5.2.21 Connect the 16 gauge Bare Drain wire (if strobe cable
install) from Beacon #3 to second ground lug located to the
left of TB1.
2.5.2.22 Connect the 16 gauge Brown wire from Beacon #1 wiring to
TB2-1.
2.5.2.23 Connect the 16 gauge Blue wire from Beacon #1 to TB2-2.
2.5.2.24 Connect the 16 gauge Blue wire from Beacon #2 to TB2-2.
2.5.2.25 Connect the 16 gauge Brown wire from Beacon #2 to TB2-
3.
2.5.2.26 Connect the 16 gauge Brown wire from Beacon #3 to TB2-
3.
2.5.2.27 Connect the 16 gauge Blue wire from Beacon #3 to TB2-4.
2.5.2.28 Connect the Red wire from the Sidelight #1 to fuse block
marked SL1.
2.5.2.29 Connect the Yellow wire from the Sidelight #2 to fuse block
marked SL2.
2.5.2.30 Connect the White Neutral wire from Sidelights #1 and #2
