Motherboard Components
Connectors
1. RJ45 LAN Port #1 (LAN1) + Dual USB2.0
ports (J6)
14. USB 3.0 HDR (J14)
2. Display Port (J7)
15. INTRUDER HDR (INTRD1)
3. LPC Header (J8)
16. 7pin SATA 3.0 Connector (SATA 3) (J25)
4. Port 80 Header for CPLD (J4) for EFI
17. 7pin SATA 3.0 Connector (SATA 2) (J26)
5. JTAG Header for CPLD (J3) for EFI
18. 7pin SATA 3.0 Connector (SATA 1) (J27)
6 Dual USB 2.0 Ports (USB1)
19. 7pin SATA 3.0 Connector (SATA 0) (J28)
7. RJ45 LAN Port #2 (LAN2) + Dual USB3.0
ports (J5)
20. SYS FAN (J29)
8. LAN2 LED HDR (J1)
21. 24 pin power connector (J24)
9. Port80 Debug Header and TPM HDR
(DBG_HD1)
22. Front FAN (J30)
10. Rear FAN (J2)
23. CPU FAN (J16)
11. COM port HDR (J10)
24. 4-Pin ATX Power Connector (PWRCONN1)
12. Front Panel HDR (J11)
25. LAN1 LED HDR (J12)
13. USB2.0 TYPE A Connector (J13)
Sockets/Chipset/Buttons
CPU Socket (U7E1)
iii Intel H110 (SKL PCH) (U3F1)
BIOS Socket (E1)
ii Nuvoton NCT6683D-T SIO (U3)
SIO F/W Socket (E2)
i SMB Bus Socket for CPLD (J23) for EFI
Jumpers
a ME DISABLE Jumper (J15)
c Recovery Jumper (J19)
b Clear CMOS Jumper (J17)
d Buzzer Jumper (J20)
Slots
A PCIE X16 slot (PCIE_X16_SLOT1)
B PCIE X8 slot (PCIE_X8_SLOT1, signal up to X4)
C DIMM_A0 (J8C1)
D DIMM_B0 (J8C2)
