Chapter 1: Instruction
1.1 Congratulations
You have purchased the powerful TYAN
®
S5547 motherboard, based on the Intel®
Skylake PCH (H110) chipset. The S5547 is designed to support single Intel
®
Core™ i3/i5/i7 series processor, and up to 32GB of un-buffered ECC UDIMM
DDR4 2133MHz / DDR4 memory. Leveraging advanced technology from Intel
®
, the
S5547 is capable of offering scalable 32 and 64-bit computing, high-bandwidth
memory design, and lightning-fast PCI-E bus implementation.
The S5547 not only empowers you in today‟s demanding IT environment but also
offers a smooth path for future application upgradeability. All of these rich feature
sets provide the S5547 with the power and flexibility to meet demanding
requirements for today‟s IT environments.
Remember to visit the TYAN
®
website at http://www.tyan.com. There you can find
all the information on all TYAN
®
products as well as all the supporting documentation,
FAQs, Drivers and BIOS upgrades.
1.2 Hardware Specifications
TYAN S5547 (S5547G2NR)
Processor
Supported CPU
Series
Intel Core i3/ i5/ i7 series processors
Socket Type / Q'ty
LGA1151 / (1)
Thermal Design
Power (TDP)
wattage
65W
Chipset
PCH
Intel H110
Super I/O
NCT6683D-T
Memory
Supported DIMM
Qty
(2) DIMM slots
DIMM Type / Speed
Unbuffered ECC UDIMM DDR4 2133
Capacity
Up to 32GB
Memory channel
1 Channel
Memory voltage
1.2V
Expansion
Slots
PCI-E
(1) PCI-E Gen3 x16 slot / (1) PCI-E Gen3 x8 slot
LAN
Port Q'ty
(1) GbE, (1) PHY
Controller
Intel I210-AT
PHY
Intel I219-LM
