TYAN S5547 - Page 5

http://www.tyan.com
5
Storage
SATA
Connector
(4) SATA
Controller
Intel H110
Speed
6.0 Gb/s
RAID
Non-support
Graphic
Connector type
(1) Display port
Chipset
Intel H110
Input /Output
USB
(5) USB2.0 ports (4 at rear, 1 Type-A)/ (4) USB3.0
ports (2 at rear, 2 via cable)
COM
(1) header
Display port
(1) Display Port
RJ-45
(2) GbE ports
Power
ATX 24-pin + 4-pin power connectors
Front Panel
(1) 2 x 5 header
SATA
(4) SATA-III connectors
System
Monitoring
Chipset
NCT6683D-T
Voltage
Monitors voltage for CPU, memory, chipset & power
supply
Fan
Total (4) 4-pin headers
Temperature
Monitors temperature for CPU & system environment
Others
Watchdog timer support
BIOS
Brand / ROM size
AMI / 16MB
Feature
Hardware Monitor / ACPI 5.0 / SMBIOS 3.0/PnP/Wake
on LAN / ACPI sleeping states S3,S4,S5 / Boot from
USB device ,PXE via LAN ,Storage / User
Configurable FAN PWM Duty Cycle / Console
Redirection
Physical
Dimension
Form Factor
Flex ATX
Board Dimension
9"x7.5" (228.6x190.5mm)
Operating
System
OS supported list
Please refer to our Intel OS supported list.
Regulation
FCC (DoC)
Class B
CE (DoC)
Yes
Operating
Environment
Operating Temp.
10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp.
- 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity
90%, non-condensing at 35° C
RoHS
RoHS 6/6 Compliant
Yes
Package
Contains
Motherboard
(1) S5547 Motherboard
Manual
(1) Web User's manual / (1) Quick Installation Guide
Installation CD
(1) TYAN installation CD
