Recommended Memory Population Table (Single CPU)
Single CPU Installed
Quantity of memory installed
1
2
CPU_DIMM_A0
√
CPU_DIMM_B0
√
√
NOTE:
1.√ indicates a populated DIMM slot.
2. Use paired memory installation for max performance.
3. Populate the same DIMM type in each channel,
specifically
- Use the same DIMM size
- Use the same # of ranks per DIMM
