66
3.4.2 South Bridge Configuration
HD Audio Configuration
HD Audio Subsystem Configuration Settings
DeepSx Power Policies
Configure the DeepSx Mode configuration
Enabled in S4-S5 / Disabled
Wake on LAN
Enable or disable integrated LAN to wake the system. (The wake On LAN cannot
be disabled if ME is on at Sx state.
Enabled / Disabled
SLP_LAN# Low on DC Power
Enable/Disable SLP_LAN# Low on DC Power.
Enabled / Disabled
High Precision Timer
Enable or Disable the High Precision Event Timer.
Enabled / Disabled
