87
BIOS Temp Sensor Name Explanation:
CPU_DTS_Temp
Temperature of the CPU Digital Temperature Sensor
CPU_PECI_Value
Temperature of the CPU Platform Environment Control Interface
CPU_MOS_Area
Temperature of the CPU_MOS_Area
PCH_Temp
Temperature of the PCH_Temp Area
DIMM_Area
Temperature of the DIMM_Area
CPU_DIMM_A0
Temperature of CPU DIMM A0 Slot
CPU_DIMM_B0
Temperature of CPU DIMM B0 Slot
BIOS FAN Sensor
Name Explanation
CPU_FAN
Fan speed of CPU_FAN
Front_FAN
Fan speed of Front_FAN
Rear_FAN
Fan speed of Rear_FAN
SYS_FAN
Fan speed of SYS_FAN
