Chapter 1: Instruction
1.1 - Congratulations
You have purchased one of the most powerful server solutions based on the
Intel
®
Tylersburg 5520 chipset. The TYAN
®
S7025 motherboard is designed to
support up to two Intel
®
Nehalem-EP 2S processors and up to 64GB DDR3-
800/1066/1333 memory. Leveraging the advanced technology from Intel, TYAN
®
S7025 is capable of offering a scalable 32 and 64-bit computing environment with
high-bandwidth memory design and lightning-fast PCI-E bus providing a rich
feature set with incredible performance.
TYAN
®
S7025 is designed around several different configurations which are all
detailed in the following Hardware Specification section:
1.2 - Hardware Specifications
TYAN S7025 (S7025WAGM2NR)
Supported CPU
Series
Intel
®
Xeon
®
processors 5500 series
Socket Type / QTY LGA1366 / (2)
Thermal Design
Power (TDP)
wattage
130W
Processor
System Bus
Up to 4.8/ 5.86/ 6.4GT/s with Intel QuickPath
Interconnect (QPI) support
IOH / ICH Intel
®
(2) 5520 / ICH10R
Chipset
Super I/O Winbond W83627DHG
Supported DIMM
Qty
(8) DIMM sockets
DIMM Type /
Speed
DDR3 800/1066/1333 RDIMM/UDIMM
Capacity Up to 64GB
Memory channel 6 Channels (3 Channels per CPU)
Memory
Memory voltage 1.5V
PCI-E
(4) PCI-E Gen.2 x16 slots
(1) PCI-E Gen.2 x8 slot (w/ x4 link)
(1) PCI-E Gen.2 x4 slot
Expansion
Slots
PCI (1) PCI 32-bit slot
Port QTY (2)
LAN
Controller Intel
®
82574L
Connector (2) Mini-SAS connectors (support 8 ports)
Controller LSI SAS1068E
Speed 3.0 Gb/s
Storage
SAS
RAID RAID 0/1/1E (LSI Integrated RAID)
