3.11 - Chipset Menu
This menu allows the user to customize functions of the Intel Chipsets.
Select a menu by highlighting it using the Arrow (/) keys and
pressing Enter. The settings are described on the following pages.
BIOS Setup Utility
Chipset
Advanced Chipset Settings
WARNING: Setting wrong values in below
sections may cause system to malfunction.
CPU Bridge Configuration
Northbridge Configuration
Southbridge Configuration
ME Subsystem Configuration
Configure CPU Bridge
features.
← → Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
3.11.1 - CPU Bridge Configuration Sub- Menu
BIOS Setup Utility
Chipset
CPU Bridge Chipset Configuration
CPU Revision :B0
Current QPI Frequency :x.xxxGT
Current Memory Frequency : xxxxMHz
QPI Frequency [Auto]
QPI L0s and L1 [Disabled]
Memory Frequency
Memory Mode
Demand Scrubbing
Patrol Scrubbing
Throttling-Closed Loop
Hyster temp
Guardband temp
Inlet temp
Temp Rise
Air Flow
Altitude
[Auto]
[Independent]
[Enabled]
[Enabled]
[Enabled]
[1.5 C]
[006]
[070]
[020]
[1500]
[Sea Level or Below]
Transition the links to
the specified speed
when transitioning the
links to full-speed.(if
supported by all
components)
← → Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
To Next Page
