67
Feature Option Description
CPU Bridge Chipset Configuration
Auto
4.800GT
5.866GT
QPI Frequency
6.400GT
Transition the links to the specified
speed when transitioning the links to
full-speed.(if supported by all
components)
Disabled
QPI L0s and L1
Enabled
Enable/Disable L0s and L1.
Auto
Force DDR-800
Force DDR-1066
Memory
Frequency
Force DDR-1333
Forces a DDR3 frequency slower
than the common tCk
detected via SPD.
Independent
Channel Mirroring
Lockstep
Memory Mode
Sparing
Independent: Independent channel.
Mirroring: Mirrors channel space
between channels.
Lockstep: lockstep between channel
0 and 1.
Spare: Sparing mode.
Disabled Demand
Scrubbing
Enabled
ECC Demand scrub enable/disable
Disabled
Patrol Scrubbing
Enabled
ECC patrol scrub enable/disable
Disabled
Throttling-Closed
Loop
Enabled
BIOS to program Closed Loop
throttling for memory compents.
Disabled
1.5°C
3°C
Hyster temp
6°C
Temperature Hysteresis.
Guardband temp /
Temperature guardband to apply to
DIMM temp sensor Threshold. (in
0.5°C units)
Inlet temp /
Temperature at the chassis inlet. (in
0.5°C units)
Temp Rise /
Temperature rise to the DIMM
thermal zone. (in 0.5°C units)
Air Flow /
Air speed to the DIMMs. (in units of
mm/sec)
Sea Level or
Below
1~300
301~600
601~900
901~1200
1201~1500
1501~1800
1801~2100
2101~2400
2401~2700
Altitude
2701~3000
The system altitude above sea
level(in meters)
