Appendix II: M.2 Latch Installation
This section provides a step-by-step demonstration on how to install a M.2 latch.
1. Take out the M.2 latch packs from the Accessory Box.
2. Insert the M.2 latch into the hole and then turn 90 degrees to the left as shown
below.
