NOTE:
1. √ indicates a populated DIMM slot.
2. Use paired memory installation for max performance.
3. Populate the same DIMM type in each channel, specifically
- Use the same DIMM size
- Use the same # of ranks per DIMM
Memory Population Table
Single CPU Populated
(CPU0)
Quantity of Memory Module Populated
1 2 4 8
P0_UMC0_CH_A0
Not
Recommended
v
P0_UMC1_CH_B0 v
P0_UMC3_CH_C0 v v
P0_UMC2_CH_D0 v v
P0_UMC6_CH_E0 v
P0_UMC7_CH_F0 v
P0_UMC5_CH_G0 v v
P0_UMC4_CH_H0 v v
